Thermal camera pictures showing radiant cooling and heating ceiling and wall panels
Birmingham (UK), October 2018 Our UK partner radiana (by WMS) presenting radiant cooling technology at the #granddesigns Grand Designs Exhibition at Birmingham NEC.
Two Ray Magic Gyptone® BIG™ Quattro 41 acoustical radiant panels are installed on the wall next to the entrance door of the meeting room at Clarum Homes. The two acoustical radiant panels have multiple functions: decorative, noise reduction, space conditioning (radiant cooling and heating) and also reduce the exposure to formaldehyde. In fact, Ray Magic
The Messana Team went on a mission to start-up the radiant cooling system of the world’s first fully sustainable campus in higher education: Eden Hall Campus located in the North Hill of Pittsburgh in Pennsylvania.
New house in New Canaan CT with radiant cooling panels on the ceiling. This home with radiant cooling in Connecticut was built by CMG Builder (Salvatore Zarrella). Surface temperatures in the kitchen are below 60F, with the dew point at about 55F. In the coldest part of the radiant panels, the surface temperature is just a
IR pictures taken during the start-up of Ray Magic radiant cooling and heating system in the new Headquarters of "The Fresh Connection" in Lafayette, CA. In the IR picture the Ray Magic panels are in heating mode. The surface temperature is about 80F (water supply temperature of about 90F) while the side wall are at
An other #RadiantCooling & Heating ceiling is now active with Ray Magic Beams drywall panels Panels canb be cut down to from 24 to 16" wide and 8 ft long
Infrared image of radiant cooling system at Lambert Residence, in Los Gatos CA. House is tested in radiant cooling mode. *Measurements* Outdoor temperature 85F Average indoor radiant temperature 73F Average active ceiling panel temperatures 59-65F Supply water temperature 49F Average dew point 52F High ceiling with wood ceiling beams attached on top of the Ray Magic
Start-Up of RayMagic Radiant Cooling system in the new passive office of Clarum Homes. The whole building (about 6,500sf) is powered by one 4 tons Daikin Altherma Monobloc (air to water heat pump). The Messana system also features a Neutral Temperature Dehumidification (NTD1200) and Heat Recovery Ventilation (HRV1200) to control the quality of air and
Messana Radiant Guru senses the radiant ceiling temperature with the accurate receptors of his hands. What is the surface temperature? We asked this question to our expert and Radiant Cooling system: The Radiant Guru. Messana Radiant Cooling was installed at the headquarters for Clarum Homes in Palo Alto, Ca. It is the first "passive house"
Single Family Home with radiant cooling and heating system embedded in the ceiling (Ray Magic radiant cooling panels). Digital pictures and Infrared pictures. Los Gatos, CA
