Project Description

PALO ALTO ESTATE

Exceptional contemporary Estate in Palo Alto, CA
Luxury dream home with cutting edge radiant conditioning system

Location: 4159 Old Adobe Rd, Palo Alto, CA

Building Type: Residential

Year: 2018

Area: 13,477 sf

Owner: For Sale (Golden Gate Sotheby’s International Realty)

Architect:
Adam Bittle

Brand new, exceptional contemporary gated estate of 13,000+ finished square feet located in Palo Alto on +/- 1.27 acres. Set among mature Oaks & Redwoods, the stunning architecture melds cutting edge industrial grade systems with artisan finishes. Massive windows and doors weave a seamless flow from inside to outside, affording the ability to entertain on a grand scale. In addition to the stunning interior, the home offers resort-like outdoor areas with a covered & heated deck, infinity pool, spa, outdoor kitchen, outdoor shower and firepit.

Meticulously designed custom features throughout include French oak hardwood floors, artisan designed light fixtures, rough cut limestone wine room, spa with sauna & steam room, home theater and elevator. The floor plan offers endless optionality with 5 bedrooms and 2 dens in the main home, a 2-bedroom guest house with full kitchen over the 4-car garage and generous pool house with full kitchen and bath.

PROJECT DETAILS

Conditioning System

Radiant Cooling and Heating with 101 Ray Magic gypsum ceiling panels and in-floor radiant (only in family room and master bedroom).

Powered by: three 5-ton Robur air-source reversible gas absorption heat pumps.

Fan Coils: four direct expansion supplemental fan coils for media room, gym, living area and master bedroom.

Hydronic Systems: two independent closed loops with buffer tank, one for basement and one for main and second floor. One independent loop for radiant floor. One independent loop air units.

Air quality system: the system control humidity and (IAQ) indoor air quality with one HRV unit installed in the basement and three ATU 200 units for the main and second floor.


3955

Total Radiant Ceiling/Floor Area (sf)


8982

Total Conditioned Area (sf)


44

Ratio (%)

PROJECT GALLERIES

Construction Gallery

Design Gallery

Infrared Gallery
